USB-C™ Multi Adapter (10 Functions in 1)

DisplayPort™ Alt Mode / USB™ Power Delivery Compatible
HDMI™/ VGA / Ethernet / USB™ 3.1 / SD™ & MicroSD™ / PD 3.0
Model: JCD384
$ 99.99

This pocket-sized multi-adapter provides all the ports you need for maximum productivity. It allows you to connect your laptop to an additional monitor via HDMI™ or VGA. It also connects to an ultrawide monitor. The USB-C™ multi-adapter gives you 2 USB™ Type-A ports for additional peripherals and 1 USB™ Type-A port with BC 1.2 to fast-charge your mobile devices.

With USB-C™ Power Delivery 3.0, the adapter offers both upstream and downstream charging when connected to a USB-C™ power adapter. It also provides direct access to a wired network and to your SD™ & microSD™ memory cards.

The JCD384 is perfect for small workspaces, home offices and for on-the-go!


Quantity

- +
  • OVERVIEW
  • FEATURES
  • SPECS
  • COMPATIBILITY
  • SUPPORT
  • OVERVIEW
  • FEATURES
  • SPECS
  • COMPATIBILITY
  • SUPPORT







9-Ports for All Your Connection Needs

These pocket-sized multi-adapters allow you to add an additional USB™ 3.1/SD™/Micro-SD™ computer peripheral, HDMI™ monitor or Gigabit Ethernet through your USB™ port



4K Ultra HD

High definition HDMI™ 2.0 output with 3840 x 2160 @ 30 Hz max resolution. Perfect for gaming or streaming movies on a TV. Extend your visual workplace with excellent dual-video HDMI™

HDMI™ or VGA output port

HDMI™ resolution up to 4K @ 30Hz; VGA up to 1920 x 1200 @ 60 Hz

Power Delivery 3.0

Power Delivery 3.0 provides you with more stability and better compatibility. Only have PD 2.0? Don't worry, PD 3.0 devices work with PD 2.0

5 Gbps Transfer Speed

2-port USB™ 3.0 supports transfer speeds at 5 Gbps

BC 1.2 Fast Charging

Provides up to 2.5x faster charging than standard chargers. Up to 2.4A, USB™ 3.0 SuperSpeed port supports fast charging BC 1.2 for smartphone/table/iPad® or similar device

Spring Push MicroSD™ Slot

The spring push design will make sure your memory card is inserted safely

Extra connectivity for your computer

Connect video, data and power. Connect to a computer or tablet with a single USB Type-C™ port.

Made with Durable, High Quality Materials

Match your MacBook Pro® with our premium space gray aluminum casing.

  • 9 ports with 10 functions
  • USB-C™ power delivery 3.0 provides charging power to the connected devices plus data transfer
  • Easily add a 4K HDMI™ or VGA video output
  • Reliable network connectivity via the Gigabit Ethernet port
  • USB™ Type-A with BC 1.2 to fast-charge your mobile devices
  • 2 - USB™ 3.1 Gen 1 provides up to 5 Gbps transfer speed, which is 10x faster than USB™ 2.0
  • Direct access to SD™ & microSD™ memory cards for data storage and transfer
System Requirements

Available USB-C™ port that supports DisplayPort™ alt mode and USB™ Power Delivery 2.0 or 3.0.
Please refer to the manufacturer of your hardware for more information on your device.

Hardware
audio supported
Yes
host connector

1 - USB-C™ Male

network interface
RJ45 (Gigabit Ethernet)
ports
  • 1 - USB-C™ 3.0 (provides power delivery & data transfer)
  • 2 - USB™ Type-A 3.1 Gen 1
  • 1 - USB™ Type-A 3.1 Gen 1 with BC 1.2
  • 1 - SD™ & microSD™
  • 1 - 4K HDMI™
  • 1 - VGA
  • 1 - RJ45 Gigabit Ethernet
power source
Bus-powered or self-powered
video output

1 - HDMI™ Female

1 - VGA Female

warranty
2-Year Limited
Performance
audio channel
2.1 via HDMI™
compatible networks
10 / 100 / 1000 Mbps
displays supported

1 (HDMI™ or VGA)

max data transfer rate

5 Gbps

max display refresh rate

HDMI™ @ 30 Hz
VGA @ 60 Hz

max display resolution

HDMI™: 3840 x 2160
VGA: 1920 x 1080

Mouse Specifications
Power
input current
Up to 5A
input voltage
Up to 20V
output current
Up to 4.25A
output voltage
Up to 20V
power consumption
≤ 500 mA up to 5A
power delivery
Up to 60W via USB-C™
Physical Specifications
cable length
5.4 in. (137 mm)
color
Silver
enclosure type
Aluminum
operating humidity
< 85% non-condensing
operating temperature
32 to 118°F (0 to 48°C)
product depth
0.65 in. (16.5 mm)
product height
4.72 in. (120 mm)
product weight
3.1 oz (88g)
product width
1.97 in. (50 mm)
storage humidity
< 85% non-condensing
storage temperature
14 to 149°F (-10 to 65°C)
Wireless Protocols
Special Notes
  • The adapter can connect to a USB-C™ port that doesn’t support Power Delivery but it will not pass power through the connected device
  • A 4K-capable display is required for obtaining the 3840 x 2160 resolution
  • If you are using a high-powered USB™ device, attach the USB-C™ power adapter to the power delivery port to ensure maximum performance. When using your USB-C™ power adapter, the multi-adapter powers both the adapter (with attached peripherals) and your laptop
  • To ensure files copy completely, do not remove the USB-C™ power adapter while copying files. For maximum performance, use a computer and USB-C™ power adapter equipped with PD 3.0
  • The device may become warm to moderately hot while transferring bulk data or while a USB-C™ power supply is plugged in
Package Contents
  • 1 - JCD384 USB-C™ 10-in-1 Multi Adapter
  • 1 - Quick Installation Guide
OPERATING SYSTEMS:
  • Microsoft® Windows® 10
  • macOS® 10.11 or later
  •
LAPTOPS/TABLETS:
  • MacBook™ Pro (Early 2015) and newer
  • Acer® Swift® 5
  • Lenovo® ThinkPad® A485, A285
  • Surface Pro™ 7
  • Surface Go™
PHONES/CONSOLES:

N/A

OTHERS:

N/A

NOTE:

Due to the immense number of devices and the models that may be associated with those devices, we aren’t able to list all compatible devices. If you are not sure whether your device is compatible with this product or not, please contact our customer service team.
