JVA04 HDMI™ to USB Type-C™ Game Capture Station
-
About This Product
- • 4K pass-through support (4K @ 60 fps)
- • Capture resolution up to 1080p @ 60 fps
- • Audio recording mixed – 3.5 mm Aux and Mic-in
- • Supports party chat voice for newer consoles
- • Driver free on Windows® and macOS®
- • Low power consumption with high performance
- • Free j5create capture software allows you to capture and stream games on your PC or notebook
- • Aluminum design and LED light
Our Game Capture Station, the JVA04, supports 1080p @ 60 fps Full HD video capturing with 4K @ 60 fps input and pass-through. Easily run on your Windows® or macOS® laptop/desktop with no driver needed.
Supports live commentary streaming, party chat voice mix, and mic in for newer consoles. It is compatible with other video editing software, perfect for assisting quick, live video editing.
-
JVA04 Support
-
At j5create we strive to maintain 100% customer satisfaction and functionality, no matter what product or system you may have. We have a full-time team of dedicated technical support specialists waiting to assist you and your specific needs.
Call Us: 888-988-0488
Email Us: service@j5create.com
Ticket System: Open a Ticket
-
-
JVA04 Specifications
-
Specifications
OS
Windows® 7/8.1/10, macOS® 10.8 or later, Linux® Driver Installation required on Windows® 7
Video Input
HDMI™ (up to 4K @ 60 fps) Video bypass
HDMI™ (up to 4K @ 60 fps) Video Capture Resolution
- 480i @ 60 fps
- 576i @ 50 fps
- 480p @ 60fps
- 4576p @ 50 fps
- 720p @ 50 fps
- 720p @ 60 fps
- 1080i @ 50 fps
- 1080i @ 60 fps
- 1080p @ 25 fps
- 1080p @ 30 fps
- 1080p @ 30 fps
- 1080p @ 50 fps
- 1080p @ 60 fps
USB™
Interface:
USB Type-C™ 3.1 Gen1
Device:
UAC, UVCVideo Loop Resolution
- 480i @ 60 fps
- 576i @ 50 fps
- 480p @ 60 fps
- 576p @ 50 fps
- 720p @ 50 fps
- 720p @ 60 fps
- 1080i @ 50 fps
- 1080i @ 60 fps
- 1080p @ 24 fps
- 1080p @ 25 fps
- 1080p @ 30 fps
- 1080p @ 50 fps
- 1080p @ 60 fps
- 4Kp @ 60 fps
Audio In/Out
1. Headset: 4-pole 3.5 mm phone jack (Mic in/Audio out)
*Stereo microphone supported
2. Game controller: 4-pole 3.5 mm phone jack (Mic out/Audio in)Audio Frequency
48 KHz Compression
USB™ 3.0: MJPG/YUV 4:2:2
*Uncompressed
USB™ 2.0: MJPG
*Up to 1080p @ 60 fpsEncode Format
MP4, H.264 / AVC + AAC LED Light
- Power on: Purple
- USB™ 3.0 connection: Blue (Uncompressed)
- USB™ 3.0 connection: Purple (MJPG)
- USB™ 2.0 connection: Orange
Power Consumption
- USB™ 3.0 Normal: 850 mA, Max:1050 mA
- USB™ 2.0 Normal: 800 mA, Max:1000 mA
Physical Specifications
Case Material
Aluminum Dimensions
Main body:
133.8 (W) x 64.5 (H) x 17.5 (D) mmWeight
Approximately: 142.5g Environmental
Storage Temperature
-10 – 65°C Storage Humidity
<85% non-condensing Operation Temperature
0 – 40°C Operation Humidity
<80% non-condensing
Package Contents
- JVA04 HDMI™ to USB Type-C™ Game Capture Station
- USB Type-C™ to Type A 3.0 cable 3.3 ft/1m
- Audio cable 4.9 ft/1.5m
- HDMI™ 2.0 cable 3.3 ft/1m
- Quick Installation Guide
